Toode läbiview
The AT&T EL52345 is an expandable cordless phone system featuring three handsets, an integrated digital answering system, and Caller ID/Call Waiting functionality. Designed for home or small office use, this system provides clear, interference-free communication using DECT 6.0 technology. The digital answering system offers up to 22 minutes of recording time, ensuring you never miss an important message. Each handset includes a backlit LCD screen for easy viewing of Caller ID entries and menu navigation.
This image displays the complete AT&T EL52345 cordless phone system. It includes the main base unit with an integrated digital answering system, and three cordless handsets. Two of the handsets are shown in their individual charging cradles, while the third is docked in the main base unit. The handsets feature a backlit LCD screen, a full numeric keypad, and dedicated buttons for call functions, menu navigation, volume control, speakerphone, mute, and intercom. The main base unit has controls for the answering system, including message playback, skip, repeat, and volume adjustment, along with a message counter display.
Seadistusjuhend
Follow these steps to set up your AT&T EL52345 cordless phone system:
- Aku paigaldamine: Open the battery compartment on each handset. Insert the supplied AAA batteries, ensuring correct polarity. Close the compartment cover.
- Charging Handsets: Place each handset in its respective charging cradle or the main base unit. The CHARGE indicator on the handset will illuminate. Allow at least 16 hours for the initial charge before first use.
- Ühenda baasüksus:
- Ühendage telefoniliinijuhtme üks ots baasseadme tagaküljel asuvasse TEL LINE pesasse.
- Ühendage telefoniliinijuhtme teine ots telefoni seinakontakti.
- Ühendage toiteadapteri suurem ots pistikupessa, mida ei saa seinakontakti lülitiga juhtida.
- Ühendage toiteadapteri väiksem ots baasseadme tagaküljel asuvasse POWER-pessa.
- Handset Registration: Handsets are pre-registered to the base unit. If a handset displays "To register HS..." or similar, refer to the troubleshooting section for manual registration instructions.
- Määra kuupäev ja kellaaeg: After the initial charge, the handset will prompt you to set the date and time. Follow the on-screen instructions using the MENU and SELECT buttons.
Kasutusjuhised
Kõnede tegemine ja vastuvõtmine
- Helistamiseks tehke järgmist. Vajutage TELEFON / VÄLK or KÕLARja seejärel vali number.
- Kõnele vastamiseks: Vajutage TELEFON / VÄLK or KÕLAR kui telefon heliseb.
- Kõne lõpetamiseks: Vajutage VÄLJAS/TÜHISTAMINE or place the handset in the charging cradle.
- Kordusvalimine: Vajutage TAASVALIMINE viimasele valitud numbrile helistamiseks.
Vastamissüsteem
The digital answering system records messages when you are away or unable to answer calls.
- Sisse/välja lülitamine: Vajutage ANS SISSE/VÄLJA baasseadmel.
- Sõnumi taasesitus: Vajutage MÄNGI/STOP on the base unit to listen to new messages.
- Skip Message: Taasesituse ajal vajutage JÄTA VÄLJA (right arrow) to skip to the next message.
- Repeat Message: Taasesituse ajal vajutage KORDA (left arrow) to repeat the current message. Press twice to go to the previous message.
- Delete Message: Taasesituse ajal vajutage KUSTUTA baasseadmel.
- Helitugevuse reguleerimine: Kasutage HELI ▲ or VOL ▼ on the base unit to adjust playback volume.
Helistaja ID
The Caller ID feature displays the caller's name and number (if available) on the handset screen.
- Review Kõnelogi: Vajutage CID on the handset to scroll through the call log.
- Helista tagasi: Kuigi viewing a Caller ID entry, press TELEFON / VÄLK numbrile helistamiseks.
Hooldus
- Puhastamine: Clean the phone and base unit with a soft, slightly damp lapiga. Ärge kasutage puhastusspreisid ega tugevatoimelisi kemikaale.
- Aku hooldus: To ensure optimal battery life, fully charge the handsets for 16 hours before first use. If the phone will not be used for an extended period, remove the batteries.
- Asukoht: Place the base unit in a central location away from other electronic devices (e.g., microwaves, Wi-Fi routers) to minimize interference.
Veaotsing
| Probleem | Lahendus |
|---|---|
| Valimistooni pole. | Ensure the telephone line cord is securely plugged into the base unit and the wall jack. Check if the power adapter is properly connected to the base unit and a working electrical outlet. |
| Handset displays "To register HS..." | To manually register a handset: Place the handset in the base unit. Press and hold the KUULUTAJA LOKAATOR button on the base unit for about 4 seconds until the IN USE light flashes. The handset will display "Registering..." and then "Handset Registered" when successful. |
| Halb helikvaliteet või staatiline müra. | Move the handset closer to the base unit. Ensure the base unit is not near other electronic devices that may cause interference. Check the telephone line cord for damage. |
| Handset battery does not hold a charge. | Ensure the handset is properly seated in the charging cradle. Clean the charging contacts on both the handset and cradle with a dry cloth. If the issue persists, the battery may need replacement. |
| Automaatvastaja ei salvesta sõnumeid. | Veenduge, et automaatvastaja on sisse lülitatud. Kontrollige, kas mälu on täis; vajadusel kustutage vanad sõnumid. |
Tehnilised andmed
| Funktsioon | Detail |
|---|---|
| Mudeli number | EL52345 |
| Telefoni tüüp | Juhtmeta |
| Telefonide arv | 3 (laiendatav) |
| Automaatvastaja tüüp | Digitaalne |
| Salvestusmaht | Kuni 22 minutit |
| Helistaja ID / Kõne ootamine | Jah |
| Tehnoloogia | DECT 6.0 |
| Nõutavad patareid | 3 AAA batteries (per handset) |
| Värv | Hõbedane, valge |
| Materjal | Plastikust |
| Toote mõõtmed (põhiseade) | 11.1 x 6.9 x 5.5 tolli |
| Kauba kaal | 1.3 naela |
| Ühilduvad seadmed | PSTN-võrgud |
Tugi ja garantii
For further assistance, technical support, or warranty information regarding your AT&T EL52345 cordless phone system, please refer to the official AT&T product support channels. Typically, warranty details are provided with the product packaging or can be found on the manufacturer's official websaidile.
Note: No official product videos were provided in the source data for embedding in this manual.
